Type:

Piezomed
SA-320

Piezomed Plus module
SA-435 M

Piezomed Classic module
SA-430 M

Supply voltage:

100–130 V/220–240 V

100–240 V

Frequency:

50–60 Hz

Permitted voltage fluctuation:

±10%

Nominal current:

0.1–1.0 A/0.1–0.5 A

1.6 A

Mains frequency:

50–60 Hz

Maximum output US:

20 W*

24 W

18 W

Operating frequency:

22–35 kHz

Coolant flow rate at 100%:

at least 60 ml/min

at least 90 ml/min

Length of handpiece cable:

1.8 m/3.5 m

1.8 m/3.5 m

1.8 m without light

Dimensions in mm (height × width × depth):

256 × 305 × 109

90 × 140 × 285

Weight:

7 kg

0.7 kg

0.6 kg

Foot control:

S-N1/S-NW with SPI dongle

S-N2/S-NW
